Materials for use in Custom Metal Fabrication Parts by Stur-Dee Metal Products
Stur-Dee Metal Products Inc. Call 773-523-3074 or fax 773-523-8281 today for an estimate!

Stur-Dee Metal fabricates custom metal pieces in steel, aluminum and stainless steel.

Our practice of "no job too small" means we’ll put our metal expertise to work for you, utilizing whatever metal is required for your custom metal fabrication part request. Please contact us for specific questions or metal needs. The table below gives more information on our available materials.

Metal Thickness Data

GA. DEC. FRAC. WT. SQ. FT.
Steel/S.S.
DEC.
ALUM.
WT SQ. FT.
ALUM.
20 0.0359 1/32 1.50 .040 .5702
18 0.0478 1/16- 2.00 .050 .7128
16 0.0598 1/16 2.50 .063 .8981
14 0.0747 1/16+ 3.125 .080 1.117
12 0.1046 1/8- 4.37 .090 1.283
11 0.1196 1/8 5.00 .125 1.782
10 0.1345 1/8+ 5.62
3/16 0.1875 3/16 7.66 .190 2.709
1/4 0.2500 1/4 10.20 .250 3.564
5/16 0.3125 5/16 12.75
3/8 0.375 3/8 15.30 .375 5.346
1/2 0.500 1/2 20.42 .500 7.128


Four Way Floor Plate

GA. DEC. FRAC. WT. SQ. FT.
Steel/S.S.
DEC.
ALUM.
WT SQ. FT.
ALUM.
12 1/8- 5.25 .100 1.6
1/8 1/8 6.16 .125 1.9
3/16 3/16 8.71 3/16 2.8
1/4 1/4 11.26 1/4 3.7
3/8 3/8 16.37 3/8 5.4
